SKU: -
Category: Automotive Connectors
Availability: 0
Tag: 1-1418479-1 heavy duty sealed connector series housings , 8 position housing , housing for female terminals , wire-to-wire , automotive connectors 8pos amp , te connectivity , automotive connectors , housings , 8 position , receptacle (female) , cable mount / free hanging , heavy duty sealed connector , without socket contacts
Brand: TE Connectivity
Model Number: -1418479-1
Availability: Out Of Stock.
Product SKU:
Minimum order quantity: 1
Maximum order quantity:
Listed date: 20th Mar, 2025
| TE Connectivity | |
| Product Category: | Automotive Connectors |
| Housings | |
| 8 Position | |
| 4 mm (0.157 in) | |
| Receptacle (Female) | |
| Cable Mount / Free Hanging | |
| Crimp | |
| Black | |
| Bulk | |
| Application: | Wire to Wire |
| Brand: | TE Connectivity |
| Contact Gender: | Without Socket Contacts |
| Flammability Rating: | UL 94 V-0 |
| Height: | 31.25 mm |
| Housing Material: | Polybutylene Terephthalate (PBT) |
| Ingress Protection: | IP67 |
| Length: | 44 mm |
| Locking Mechanism: | On the terminal |
| Maximum Operating Temperature: | + 140 C |
| Minimum Operating Temperature: | - 40 C |
| Mounting Angle: | Straight |
| Number of Rows: | 2 Row |
| Product Type: | Automotive Connectors |
| Row Spacing: | 9 mm |
| Subcategory: | Automotive Connectors |
| Type: | Receptacle Housing |
| Width: | 25.7 mm |
| Unit Weight: | 50 g |
