Heavy Duty Sealed Connector

In stock

1-1564514-1 Heavy Duty Sealed Connector

SKU: 1-1564514-1

Category: Automotive Connectors

Availability: 1000

0.00/5 (0 Review)

₹ 358.25

Tag: te connectivity , automotive connectors , cable mount / free hanging , heavy duty sealed connector , wire to wire , without socket contacts

Quantity:

Total: ₹ 358.25

Add to wishlist Add To Compare

Share on:

Description

10 Position Housing, Housing for Female Terminals, Wire-to-Wire, 4 mm / 6 mm [.157 in / .236 in] Centerline, Heavy Duty Sealed Connector Series

Product Specifications

Brand: TE Connectivity

Model Number: 1-1564514-1

Availability: In stock

Product SKU: 1-1564514-1

Minimum order quantity: 1

Maximum order quantity:

Listed date: 27th Jun, 2025

Manufacturer:	TE Connectivity
Product Category:	Automotive Connectors
Product:	Housings
Number of Positions:	10 Position
Pitch:	4 mm, 6 mm
Gender:	Receptacle (Female)
Mounting Style:	Cable Mount / Free Hanging
Application:	Wire to Wire
Brand:	TE Connectivity
Contact Gender:	Without Socket Contacts
Flammability Rating:	UL 94 V-0
Height:	31.25 mm
Housing Material:	Polybutylene Terephthalate (PBT)
Ingress Protection:	IP67
Length:	54.1 mm
Locking Mechanism:	On the terminal
Material:	Polybutylene Terephthalate (PBT)
Maximum Operating Temperature:	+ 140 C
Minimum Operating Temperature:	- 40 C
Product Type:	Automotive Connectors
Row Spacing:	6.9 mm
Subcategory:	Automotive Connectors
Type:	Heavy Duty
Voltage Rating:	42 VDC
Width:	25.7 mm
Unit Weight:	226.800 g

Pdf Specifications

download file
