SKU: 282192-1 4 POLE CONNECTOR
Category: Automotive Connectors
Availability: 1000
Tag: te connectivity , amp superseal 1.5 , 4-pole connector , waterproof receptacle , ip67 sealed connector , 4-way automotive connector , te 4-pin female housing , compact sealed connector , engine compartment connector , weatherproof connector , cable-to-cable connector , te amp 4-pin receptacle
Brand: TE Connectivity
Model Number: 282192-1
Availability: In stock
Product SKU: 282192-1 4 POLE CONNECTOR
Minimum order quantity: 50
Maximum order quantity:
Listed date: 30th Jul, 2025
| Parameter | Details |
|---|---|
| Part Number | 282192-1 |
| Manufacturer | TE Connectivity |
| Series | AMP Superseal 1.5 |
| Connector Type | Receptacle Housing (Female) |
| Number of Positions | 4 |
| Contact System | 1.5 mm Terminal System |
| Mounting Type | Cable / Free Hanging |
| Sealing Rating | IP67 (with mating plug) |
| Voltage Rating | Up to 14 VDC (typical automotive systems) |
| Current Rating | Up to 14 A |
| Operating Temp. Range | -40°C to +125°C |
| Wire Range | 0.5 – 1.5 mm² (20–16 AWG) |
| Housing Material | Thermoplastic (PA66 GF), UL94 V-0 rated |
| Color | Black |
| Mating Plug | Compatible with plug housing 282080-1 |
