Brand: TE Connectivity
Model Number: 4-1437290-0
Availability:
In stock
Product SKU:
4-1437290-0
Minimum order quantity: 1
Maximum order quantity:
Listed date: 21st Feb, 2024
Product Type Features
Connector Shape : Rectangular
Connector System : Wire-to-Board, Wire-to-Device
Connector & Housing Type : Housing for Female Terminals
Sealable : Yes
Primary Locking Feature : Integrated in Housing
Mixed & Hybrid Connector : No
Configuration Features
Number of Positions : 34
Number of Rows : 4
Electrical Characteristics
Operating Voltage (VAC): 250
Operating Voltage (VDC): 250
Nominal Voltage Architecture (V): 12, 24, 42, 48, 80, 90, 125, 240
Body Features
Cable Exit Angle : 180°
Primary Product Color : Black
Connector & Keying Code : 1
Contact Features
Contact Type : Socket
Mating Pin Diameter : 1 mm [ .039 in ]
Mechanical Attachment
Mating Alignment : With
Mating Alignment Type : Keyed
Strain Relief : Without
Connector Mounting Type : Cable Mount (Free-Hanging)
Terminal Position Assurance : Yes
Housing Features
Housing Material : PBT GF
Centerline (Pitch) : 3 mm [ .118 in ]
Dimensions
Row-to-Row Spacing (mm): 3.5, 4
Row-to-Row Spacing (in): .138, .157
Product Length : 32.15 mm [ 1.266 in ]
Product Width : 38.2 mm [ 1.504 in ]
Connector Height : 34.55 mm [ 1.36 in ]
Usage Conditions
Operating Temperature (Max) (°C): 70, 75, 80, 85, 90, 100, 105, 110, 120, 125
Operating Temperature (Max) (°F): 158, 167, 176, 185, 194, 212, 221, 230, 248, 257
Operating Temperature Range : -40 – 125 °C [ -40 – 257 °F ]
Industry Standards
UL Flammability Rating : UL 94V-2
Degree of Protection : JIS D0203
Other
Connector Position Assurance Capable : No
Serviceable : Yes
