Brand: TE Connectivity
Model Number: 776286-1
Availability:
Out Of Stock.
Product SKU:
776286-1
Minimum order quantity: 1
Maximum order quantity: 2147483647
Listed date: 14th Mar, 2024
Product Type Features - Connector Shape : Rectangular
- Connector System : Wire-to-Board
- Connector & Housing Type : Housing for Female Terminals
- Sealable : Yes
- Connector & Contact Terminates To : Wire & Cable
- Primary Locking Feature : Integrated in Housing
- Mixed & Hybrid Connector : No
Configuration Features - Number of Positions : 8
- Number of Rows : 3
Electrical Characteristics - Operating Voltage (VAC): 250
- Nominal Voltage Architecture (V): 250
Body Features - Cable Exit Angle : 180°
- Primary Product Color : Black
- Connector & Keying Code : 1
Contact Features - Contact Type : Socket
- Contact Size : 1.3mm
- Mating Pin Diameter : 1.3 mm [ .051 in ]
- Contact Current Rating (Max) (A): 17
Mechanical Attachment - Mating Alignment : With
- Mating Alignment Type : Keyed
- Strain Relief : Add By Accessory
- Connector Mounting Type : Cable Mount (Free-Hanging)
- Terminal Position Assurance : Yes
Housing Features - Housing Material : PBT GF
- Centerline (Pitch) : 4 mm [ .157 in ]
Dimensions - Row-to-Row Spacing : 4 mm [ .157 in ]
- Product Length : 27.4 mm [ 1.079 in ]
- Product Width : 33.6 mm [ 1.323 in ]
- Connector Height : 34.6 mm [ 1.362 in ]
Usage Conditions - Operating Temperature (Max) : 125 °C [ 257 °F ]
- Operating Temperature Range : -40 – 125 °C [ -40 – 257 °F ]
Operation/Application - Circuit Application : Power & Signal
Industry Standards - UL Flammability Rating : UL 94V-0
- Degree of Protection : IP67, IP69K
Packaging Features - Packaging Method : Box & Tray
- Packaging Quantity : 280
Other - Connector Position Assurance Capable : Yes
- Serviceable : Yes
