SKU: TE Connectivity 1-1564536-1
Category: Automotive Connectors
Availability: 1000
Tag: 4 position housing , housing for male terminals , wire-to-wire , 9 mm [.354 in] centerline , sealable , black , heavy duty sealed connector series
Brand: TE Connectivity
Model Number: 1-1564536-1
Availability: In stock
Product SKU: TE Connectivity 1-1564536-1
Minimum order quantity: 50
Maximum order quantity:
Listed date: 17th Jul, 2025
| TE Connectivity | |
| Product Category: | Automotive Connectors |
| RoHS: | |
| Housings | |
| 4 Position | |
| 9 mm (0.354 in) | |
| Plug (Male) | |
| Cable Mount / Free Hanging | |
| Black | |
| Heavy Duty Sealed Connector | |
| Brand: | TE Connectivity |
| Contact Gender: | Without Pin Contacts |
| Flammability Rating: | UL 94 V-0 |
| Housing Material: | Polybutylene Terephthalate (PBT) |
| Ingress Protection: | IP67 |
| Maximum Operating Temperature: | + 140 C |
| Minimum Operating Temperature: | - 40 C |
| Number of Rows: | 1 Row |
| Product Type: | Automotive Connectors |
| 150 | |
| Subcategory: | Automotive Connectors |
| Type: | Tab Housing |
| Voltage Rating: | 60 VDC |
| Unit Weight: | 37.528 g |
